Haspolat Septage Receiving Facility, Northern Cyprus

The electrical and automation works of this facility, which receives 30,000 m³ of septage per day, were delivered by a single contractor: from the MV kiosk substation and generator to the main distribution and MCC panels, and the PLC and SCADA software.

Electrical infrastructureMV kiosk substationGeneratorMDBMCCPLCSCADAPartner: Mono Arıtma

30,000 m³/day

receiving capacity

Nicosia, Northern Cyprus

Güzelyurt Biological Wastewater Treatment Plant, Northern Cyprus

Biological domestic wastewater treatment plant. The scope included 4 × 25 kW CHP units, a belt press and the plant's PLC and SCADA system.

CHP 4 × 25 kWBelt pressPLCSCADAPartner: Temser Çelik · Gökşin İnşaat – Instal Warszawa

2,700 m³/day

treatment capacity

Güzelyurt, Northern Cyprus

Gazimağusa Wastewater Pumping Stations, Northern Cyprus

Revision of the wastewater pumping stations across the city: MCC and PLC panels, AC drive pump control, and a SCADA and telemetry infrastructure monitoring the stations from a single centre.

MCCPLCAC driveSCADATelemetryPartner: Temser Çelik

City-wide

pumping stations

Gazimağusa, Northern Cyprus

Package Treatment Systems

Compact PLC and HMI panels for containerised reverse osmosis package treatment systems. The panels were built in Istanbul and exported together with the system.

Compact panelPLCHMIExport

1,000 L/day

reverse osmosis

Export

Bolvadin Wastewater Pumping Station

MCC and PLC panel of the pumping station: level-based control of three submersible pumps with runtime equalisation, gas detection (CH₄, H₂S, NH₃) and ventilation automation, operator panel and remote monitoring.

MCCPLCHMIGas detectionRemote monitoring

3 pumps

runtime-equalised control

Bolvadin

Sinop Solid Waste Mechanical Separation Facility

MCC and PLC panels, SCADA software and site electrical installation for a mechanical separation facility processing 25 tonnes of waste per hour.

MCCPLCSCADASite electrical installationPartner: SG Makina

25 tonnes/hour

separation capacity

Sinop

Bartın Solid Waste Mechanical Separation Facility

MCC and PLC panels, SCADA software and site electrical installation for a mechanical separation facility processing 25 tonnes of waste per hour.

MCCPLCSCADASite electrical installationPartner: Ünallar Makina

25 tonnes/hour

separation capacity

Bartın

Kayseri Biogas Plant

At the operating plant, the MCC panels were reorganised and the control logic improved. Technical service support was provided to the plant.

MCCControl logicTechnical servicePartner: Enviren Biogaz

Kayseri

Eskişehir Biogas Plant

PLC control, MCC panel and on-site commissioning of the desulphurisation unit that removes H₂S from the biogas.

DesulphurisationPLCMCCCommissioningPartner: Enviren Biogaz

Eskişehir

Liquid Fertiliser Production: İzmir, İzmit, Tekirdağ

MDB, MCC and PLC panels for the liquid fertiliser production systems at three factories, with weighing load cell integration.

MDBMCCPLCLoad cell

3 factories

8 tonnes of liquid fertiliser production

İzmir · İzmit · Tekirdağ

İzmit Tyre Production Lines

Micron-level defect detection on tyre production lines using SICK sensors and industrial cameras, and revision of the existing PLC system.

SICK sensorsIndustrial cameraPLC revisionPartner: Körfeztek Teknoloji

İzmit

Press Lines

The PLC panels of 16 presses of 250 tonnes each were fully revised; the fixture and grip-and-release systems were rebuilt.

PLC panel revisionFixturesGrip-and-releasePartner: Körfeztek Teknoloji

16 × 250 tonnes

presses

Sandblasting Facilities

MCC and PLC panels, HMI programming and site electrical installation for the shipyard's sandblasting facilities.

MCCPLCHMISite electrical installation

Occupational Safety Automation

Monitoring of hazardous zones with SICK laser area scanners and implementation of safety scenarios.

SICK laser scannerSafety scenariosPartner: Körfeztek Teknoloji

Latvia and Estonia Factories

10 conveyor panels were built and exported for two factories.

Conveyor panelExportPartner: Flexkon Konveyör

10 panels

conveyor panels

Latvia · Estonia

Factory Distribution Boards

Revision of all main distribution boards (MDB) and sub-distribution boards across the factory.

MDBSub-distribution boards

Factory-wide

panel revision

Corrugated Board Plant, İzmit

Revision of the plant's electrical infrastructure: neutral-earth separation, LOTO implementation and residual current relays.

Neutral-earth separationLOTOResidual current relayPartner: Körfeztek Teknoloji

İzmit

Piazza Shopping Centre

PLC revision of 82 air handling units and their integration into the building management system (BMS), including VRV/VRF systems.

PLC revisionBMS integrationVRV/VRFPartner: Eneko Havalandırma

82 AHU

air handling units

Delivered. Running.
